#Inkscape gcode for laser engraver text how to

This extension warns if the target graphics are larger than allowed engraving range, and you should scale it down and try again. It is noted in the dropdown list of the entension for your reference.

Maximum engraving range depends on the model of your LP. (0=off, which makes the Gcode useless, so I disallowed it.)

Laser power can be set from 1 (min) to 255 (max).

I tested speeds from 0.01mm/min to 70mm/min and they all came out the same on the engraver end. The lowest laser speed is limited to 70mm/min, as this is the lowest effective speed that LaserPecker App allows.Faster or slower than the engraver's top speed does not matter much.Laser head idle movement speed is hard-coded to 6000mm/min. Restart Inkscape and you should be able to access the extension from Extensions > LaserPecker > Gcode Generator for L1/Pro/L2.For Windows: C:\Program Files\Inkscape\share\inkscape\extensions\.For Mac: Launch Inkscape > Preferences > System > Look for User extensions > click Open.Flatpak: ~/.var/app//config/inkscape/extensions/.For Linux: ~/.config/inkscape/extensions/.

Depending on your Inkscape version and operating system, download laserpecker.inx and laserpecker.py from extension/ / directory into.

#Inkscape gcode for laser engraver text how to

Install Inkscape v0.92 or newer and watch this video on how to download a file from GitHub.

Compatibilityīefore generating Gcode for LP, please select the correct model and firmware number. LaserPecker is a brand of affordable and portable consumer level laser engravers.įor more details, visit The Unofficial Wiki for LaserPecker. Please consider using the built-in Gcode mode first. The LaserPecker App already has a built-in Gcode converter with capability of line-filling, which is pretty easy to use. This is a Gcode generator extension for Inkscape, that will generate Gcode compatible with LaserPecker engravers.
